The LogoIt! HD-SDI Logo Inserter from ChyTV is a logo insertion system designed to help you create your company or channel ID and branding look on your video output signal. LogoIt! can create anything from simple static logos to complex pages of graphics, logos, text, and tickers. This system can be used for digital signage in college/high school sports & live events, news studios, remote production trucks, live control rooms, master control rooms, and more.

Incorporating both hardware and Windows-based software, LogoIt! provides a comprehensive set of tools to create, manage, and playback a wide variety of logos, text, and graphic images. Commands are available to size and position any logo or graphic element on the screen and save for future recall. Saved logos are displayed in the provided asset browser allowing the operator to recall logos by clicking on the graphic or by recalling using the supplied dedicated control panel. Designed to ease the operator's task, LogoIt!'s simple to use interface minimizes the chances of on-air mistakes.

LogoIt! enables you to add text and automated multiple static fields and/or multiple crawl tickers with interpolated static or animated graphic elements to your on air station identification, or other logos. Text elements can be used in conjunction with other graphics or by themselves. Fonts, colors, speed, speed changes, segment separators (static or animated) can be adjusted independently for each ticker line. Tickers provide a way to automatically update onscreen text with data coming into LogoIt! from either Ethernet or RS232 connections. Analog and Digital clocks, up & down counters, SMS messages, and temperature updates are just some examples of how this function could be used.

The background combiner and restyling tools allow you to create 32-bit transparent logos and/or backgrounds, using the standard video capture feature. Once images are captured they are available on the network so they can be shared with other workstations in the graphics department. Software tools are provided to convert pairs of 24-bit graphics files and create valid 32-bit logos. Any SDI source connected to the LogoIt! video input can provide the fill and key required. The background combiner will match them together to create a 32-bit graphics file which can be used as a logo or background. The restyling tools complement the combiner with graphics processing, painting, and editing capability.

The LogoIt! includes a 2' breakout cable for analogue input\output. The cable connects to the unit via a DB25 connector, and features 6 BNC connectors (component video - three in, three out), and four balanced XLR connectors (audio - two in, two out).
