The AJA LUT-box allows you to load 3D LUTs via USB to adjust the color space from a source signal, ensuring that every monitor you use shows the correct look for that signal. It supports 3D LUTs at 17x17x17 at 12-bit processing in .lut, .txt, .3dl, .cube file formats. Featuring HDMI and 3G-SDI outputs, it lets you output to HDMI and SDI monitors at the same time from a single unit. The original footage is maintained in an alternate color space so you can take advantage of additional dynamic range.

Using a free-to-download AJA MiniConfig control software, you get to select 8 of 16 SDI embedded audio channels and pass them to the HDMI output. Two channels of RCA audio output allow you to pass separate RCA audio at the same time with your HDMI audio. MiniConfig also provides detailed information about the current input and output formats, allows you to control all the parameters of the LUT-box, and lets you download firmware updates. It's compatible with Mac and PC and interfaces with the LUT-box via a USB connection between the LUT-box and the computer.

LUT-box features a compact, portable, and rugged design and comes with a 3.2 ft HDMI cable and a universal power supply with international plugs for use around the world.
