The Prism Sound Atlas is a 2 RU rack-mountable USB audio interface designed to deliver reliable precision, high-resolution, and multichannel audio I/O for musicians, vocalists, songwriters, and audio engineers in home, project, commercial, and mobile studios. Its stable clock allows operation at up to 24-bit / 192 kHz resolution with high jitter rejection. With latency as low as 0.08 ms, it is well suited for recording, overdubbing, and even send-and-return routing.

Line or microphone sources can be connected via the eight XLR-1/4" combo inputs, while two front-panel 1/4" jacks accommodate instruments such as guitars or synthesizers. Phantom power is selectable as are the input pads and built-in limiters. The eight 1/4" line outputs are ideal for connection to speakers and power amps, while the front-panel 1/4" jacks offer dedicated level and mix controls for independent headphone monitoring. Additionally, digital connectivity includes RCA coaxial for S/PDIF or AES3, TOSLINK optical for S/PDIF or ADAT, and BNC for word clock. An RJ45 port is present for future AVB integration.

The Atlas is compatible with Mac OS X and Windows systems via its class-compliant USB 2.0 connectivity. An IEC power cable, USB cable, rackmount ears, and XLR to RCA adapters are included.
