The Pixel Driver 1000IP from Elation Professional is designed specifically for the Elation Pixel Bars 30IP, 60IP, and 120IP series. It provides easy and versatile control options, including simple onboard manual dimming, strobe control, and full-pixel mapping control of 1020 max pixels via Kling-Net and 170 max pixels via Art-Net and sACN (streaming ACN) protocols.

The Pixel Driver 1000IP features a rugged IP65 housing, universal auto-switching power supply (100-240V), 4-button LCD control menu display, RJ45 Ethernet in/out ports, and a proprietary 4-pin IP65 XLR-type output that supplies power and data to the pixel bars connected to it. The Pixel Driver 1000IP can be mounted on a standard 19" rack (rack ears included) or attached to a truss with a Pro clamp (not included).
